Our products are not OEM, they are only compatible parts
XGY-090647234 1351800950
XGY-090647234 1351800950
| Quantity: | |
|---|---|
Name: Putter; Code: 0906474234 / 1351800950. Filling machine filling valve mechanism, bottle/can lifting or clamping mechanism, capping/screw-on capping/press-on capping mechanism, rinsing/draining/pneumatic control valve assembly
Our products are not OEM, they are only compatible parts.
Product Description
Appearance and Structure: The body consists of a slender, cylindrical metal rod with a surface that has undergone precision grinding and polishing, resulting in a bright silver finish. The middle section of the rod features a positioning step or stop ring (or a shoulder for adjustment or connection); one end is a thinner working end or insertion end, while the other end is a head or connection end (which may be used to abut against a valve core, follower, or cam/cylinder mechanism). Some sections may have transverse pin holes, threads, or flat surfaces to prevent rotation or secure the rod in place.
Material speculation: Food/filling equipment commonly uses 316L stainless steel or surface-hardened/coated high-alloy steel to ensure resistance to wear, corrosion, and CIP/SIP cleaning media. Krones filling valve moving parts typically emphasize dimensional tolerances, straightness, and surface roughness.
Application Scenarios
1. Filling valve mechanisms in filling machines (Modulfill, volumetric fillers, etc.): Functioning as a valve-internal plunger or push rod, these components are driven by an external cam or pneumatic/electric actuator to move the valve core up and down or open/close the flow channel, thereby enabling operations such as filling start/stop, venting, and residual discharge.
2. Bottle/Can Lifting or Pressing Mechanism: Transmits lifting or pre-compression motion when the filling head descends to seal against the bottle or can opening.
3. Capping/Screw-On/Press-On Mechanism: Acts as a motion transmission rod to control the axial movement of the press head, clamping jaws, or valve core.
4. Rinsing/Drainage/Pneumatic Control Valve Assembly: Acts as a guide push rod when axial force is required to move seals or valve needles.
Xinguangyuan Precision Machinery Co., Ltd.Produces a large number of machine and equipment parts, as well as high-performance PET blow molding machines, filling machines, capping machines, and labeling machine precision parts. Suitable for various brands, including KRONES/SIDEL/KHS/Sacmi/Newam star/TECH-IONG/Tetra Pak Wait, you can provide a drawing or customize according to a sample. With over ten years of experience in the PET industry, we have accumulated rich R&D and manufacturing experience, and we continuously improve our processes. All spare parts we produce meet high-quality standards.
With professional services, high-quality products, and competitive prices, we have established a reliable reputation among our customers, achieving mutual benefits and win-win cooperation.
Blow molding and hydraulic buffers, filling assemblies, capping assemblies, rubber-sealed bearings, maintenance kits, compensating air hoses; production and service of cooling water pipes, PTFE heating tubes, PEEK/PET modified engineering plastics, and ceramic products.
