XGY-1018320990
XGY-1018320990
| Quantity: | |
|---|---|
Guidance Device, Part Number 1018320990. Used in the bottle infeed/outfeed conveyor sections, buffer stations, lane splitting/merging zones, star wheel inlet/outlet transition zones, and at the inlets or outlets of filling, capping, labeling, and inspection equipment on Krones machines, as well as near bottle clamps, bottle clamp star wheels, or handling mechanisms.
Our products are not OEM, they are only compatible parts.
Structure: The entire component consists of a polished/machined or precision-cast metal part, featuring a cylindrical mounting/connection boss at the center of the top (which may be used for securing pins, bolts, or connecting guide rods, sensors, or limiters). It has a support leg/brace structure on both sides, with through holes, waist holes, or countersunk holes on the sides for mounting and securing, weight reduction, or threading bolts/pins for positioning. The bottom features a curved or arched channel design, allowing bottles, cans, fixtures, or conveyed items to pass through from below or in the center while maintaining a controlled path.
Material Speculation: Common materials for food and beverage lines include 304 or 316L stainless steel, with polished, brushed, or precision-finished surfaces to facilitate cleaning and ensure resistance to corrosion, CIP, disinfectants, and humid environments.
Features: High rigidity and smooth, chamfered contours to minimize liquid accumulation and sanitary dead zones; as guide/stop components, dimensional and positional accuracy directly affect bottle flow stability.
Application Scenarios
1. Bottle Infeed/Outfeed Conveyor Sections, Buffer Stations, and Lane Splitting/Merging Zones: Guides PET/glass bottles or cans to maintain proper spacing and orientation, preventing misalignment, bottle tipping, and label collisions.
2. Star Wheel Inlet/Outlet Transition Zones: Works in conjunction with guardrails, guide plates, and bottle-separating screws/divider wheels to smoothly feed containers into or out of star wheels or turntables.
3. Inlets or outlets of filling, capping, labeling, and inspection equipment: Function as overhead or lateral guides, height limiters, or misalignment preventers to control the trajectory of the bottle body and neck.
4. Near bottle clamps, star wheels with bottle clamps, or handling mechanisms: May be used to restrict the movement of clamps or maintain container orientation (refer to the BOM assembly drawing for specifics).
Functions
1. Guidance/Limiting: Restricts the movement path of containers or fixtures to maintain channel width, height, and phase.
2. Anti-tipping and Anti-collision: Reduces swaying, collisions, and label scratches during high-speed conveyance, track changes, and entry into star wheels or turntables.
3. Smooth Transition: Provides a smooth guiding surface between the conveyor surface and the star wheel or mechanism, reducing the risk of bottle jamming or bouncing.
4. Mounting and Alignment: Top bosses and side holes/mounting tabs are used for reliable fastening or connection to other guiding, sensing, or limiting components.
5. Hygiene and Durability: The polished metal construction is suitable for cleaning environments and maintains dimensional stability over the long term.
Krones is a registered trademark. Our Guidance Device is a compatible replacement part and not manufactured or endorsed by Krones. All product names, trademarks, and brands mentioned are the property of their respective owners, used only for compatibility reference.
