XGY-8L100000128
XGY-8L100000128
| Quantity: | |
|---|---|
Our products are not OEM, they are only compatible parts.
Product Description
Integrated multi-step precision stepped drive shaft with locating shoulders and assembly grooves on the shaft body; the shaft is precision-machined to strict dimensional tolerances; Made of alloy steel, it undergoes quenching and tempering heat treatment followed by a black oxide wear-resistant surface treatment, providing resistance to torsion and fatigue; individually packaged for protection, its structure complements that of the screw shaft (part number XGY-8L100000129) to form a complete screw drive assembly, transmitting the rotational force required for mold height adjustment.
Application Location
Sacmi PHC Ceramic Hydraulic Press Mold Base Adjustment Mechanism: Upper end of the screw assembly; the upper section of the complete mold height adjustment screw drive assembly, which is mated to the lower end of the screw shaft (part number XGY-8L100000129). The upper end connects to the screw-nut mechanism, while the lower end is mated to the lower end of the screw shaft. The entire mechanism is used to adjust the height of the mold cavity.
Functions
1. Torque Transmission: Transfers rotational power to the mold frame adjustment screw to enable electric lifting and lowering adjustments of the mold height and mold frame clearance.
2. Radial Positioning Support: Multiple shoulder-based positioning points control the radial runout of the screw assembly, ensuring coaxiality of the transmission and minimizing mold adjustment offset.
3. Drive Connection: Acts as the upper drive shaft, connecting the drive end to the lower screw shaft to fully transmit power to the entire screw mechanism.
4. Load Bearing: Withstands torsional forces and radial loads during die adjustment operations, maintaining stable operation of the screw assembly.
Features
1. Precision Machining: High dimensional accuracy; direct replacement without secondary machining.
2. Quenched and tempered alloy steel + blackened wear-resistant surface: High torsional strength; rust and wear resistance in powder handling applications; resistant to deformation and shaft breakage during repeated start-stop cycles.
3. Multi-step positioning structure: Stepped shoulders precisely position bearings and bushings, simplifying assembly and ensuring good coaxiality.
4. Paired set: Forms a complete set with the XGY-8L100000129 screw shaft; replacing the entire set ensures smoother operation and adjustment.
5. High Interchangeability: Part numbers are universal across the PHC press series, enabling quick replacement of spare parts and reducing press downtime for maintenance.
6. Excellent Fatigue Resistance: Suitable for high-frequency die adjustment operations in presses, withstanding continuous alternating torsional stress.
Why Choose Us
Company introduction
Xinguangyuan Precision Machinery Co., Ltd.Produces a large number of machine and equipment parts, as well as high-performance PET blow molding machines, filling machines, capping machines, and labeling machine precision parts. Suitable for various brands, including KRONES/SIDEL/KHS/Sacmi/Newam star/TECH-IONG/Tetra Pak Wait, you can provide a drawing or customize according to a sample. With over ten years of experience in the PET industry, we have accumulated rich R&D and manufacturing experience, and we continuously improve our processes. All spare parts we produce meet high-quality standards.
*Replacement parts are not manufactured by the original equipment manufacturer. These SPARPAE RTS parts for brands such as KRONES®, SIDEL®, KHS®, SACMI®, AROL®, SIG®, SIPA®, and TECH-LONG® are alternatives to original equipment manufacturer parts; they are primarily manufactured in China and sold worldwide. All product names, trademarks, and brands mentioned are the property of their respective owners, used only for compatibility reference.
